The goal at Piranha is to improve your production efficiency by speeding your production, increasing your accuracy, and reducing your fabrication cost.

Their lines of metal fabrication machinery will help you deliver the highest quality with greater profits. Piranha solutions include fiber LASERs, punch-plasma combination machines, plasma cutting machines, heavy-duty hydraulic bending rolls, ironworkers, press brakes, plasma tables, and an extensive line of machine tooling.

Their team is constantly at work to find new solutions that produce more precise parts, in the least amount of time.

Untitled design (80)
p50-800x

P-50 Single Operator Ironworker Machine

Piranha P-50 ironworker machines are the entry-level of the iconic line of Piranha ironworkers, but they don’t lack the toughness and precision that is expected from a Piranha Ironworker. They are just the right tool for many jobs.

  • Punch Station
  • Angle Shear
  • Flat Shear Station
  • Coper-Notcher Station
  • Urethane Stripper Assembly
  • Hold Down Assembly
  • Electric Foot Switch
  • Electric Limit Switches
p65-800x

P-65 Single Operator Ironworker Machine

The Piranha Model P-65 is Piranha’s most popular model of ironworker machine. The P-65 has more standard workstations than any other ironworker in its class. This includes punching, bending, bar shear, angle shear, round bar shear, and an integrated coper/notcher. It also has a dovetail slide that allows an operator to switch from punching to bending in just a few seconds.

  • Complete Punching Attachment with split dovetail mounting
  • 5 Punch and Die sets
  • Automatic Urethane Hold Down on the Punch Stripper and on Angle
  • Plate and Bar Shear
  • Front and rear 5 position joystick controls (electric) with  jog up & down, fast up & down, neutral
  • Remote Electric Foot Switch that can be connected at either end of the machine
  • Electric Limit Switches that can be set for stroke control when using the foot control
  • Set of Round Bar Knives [2 way] (customers choice to 1-1/2″)
  • Set of 12.125 Plate Shear Knives [4 way]
  • Set of Angle Knives [8 way top] [4 way bottom]
  • Set of Coper Knives [2 way top] [4 way bottom]
  • Chip Buckets (2 each)
  • Extra Oil Filter
  • Coupling Wrench & 3/8″ Allen Wrench
  • Integral Lifting Lug for instant portability
p90

P-90 Single Operator Ironworker Machine

The Piranha Model P-90 ironworker picks up where the P-65 leaves off – for applications requiring more tonnage. The P-90 has more standard workstations than any other ironworker in its class. This includes punching, bending, bar shear, angle shear, round bar shear, and an integrated coper/notcher. The P-90 also has a dovetail slide that allows an operator to switch from punching to bending in just a few seconds The P-90 has full electrical control of its stroke with a footswitch and limit switch stroke controls.

  • Complete Punching Attachment with split dovetail mounting
  • 5 Punch and Die sets
  • Automatic Urethane Hold Down on the Punch Stripper and on Angle
  • Plate and Bar Shear
  • Front and rear 5 position joystick controls (electric) with jog up & down, fast up & down, neutral
  • Remote Electric Foot Switch that can be connected at either end of the machine
  • Electric Limit Switches that can be set for stroke control when using foot control
  • Set of Round Bar Knives [2 way] (customers choice to 2)
  • Set of 14.50 Plate Shear Knives [4 way]
  • Extra Blank Knife to extend shear to 18″
  • Set of Angle Knives [8 way top] [4 way bottom]
  • Set of Coper Knives [2 way top] [4 way bottom]
  • Chip Buckets (2 each)
  • Extra Oil Filter
  • Coupling Wrench & 3/8″ Allen Wrench
  • Integral Lifting Lug for instant portability
p110

P-110 Single Operator Ironworker Machine

The Piranha Model P-110 ironworker machine is a strong workhorse capable of performing in heavy applications. The P-110 has more standard workstations than any other ironworker in its class. This includes punching, bending, bar shear, angle shear, round bar shear, and an integrated coper/notcher. The P-110 also has a dovetail slide that allows an operator to switch from punching to bending in just a few seconds The P-110 has full electrical control of its stroke with a footswitch and limit switch stroke controls.

  • Complete Punching Attachment with split dovetail mounting
  • 5 Punch and Die sets
  • Automatic Urethane Hold Down on the Punch Stripper and on Angle, Plate and Bar Shear
  • Front and rear 5 position joystick controls (electric) with jog up & down, fast up & down, neutral
  • Remote Electric Foot Switch that can be connected at either end of the machine
  • Electric Limit Switches that can be set for stroke control when using foot control
  • Set of Round Bar Knives [2 way] (customers choice to 2)
  • Set of 16.625 Plate Shear Knives [4 way]
  • Set of 20.5″ Plate Shear Knives [4 way] (instead of Round Bar Knives and 16.625″ Plate Shear Knives)
  • Extra Blank Knife to extend shear to 20.5″
  • Set of Angle Knives [8 way top] [4 way bottom]
  • Set of Coper Knives [2 way top] [4 way bottom]
  • Chip Buckets (2 each)
  • Extra Oil Filter
  • Coupling Wrench & 3/8″ Allen Wrench
  • Integral Lifting Lug for instant portability
p140

P-140 Single Operator Ironworker Machine

With 140 tons of punching force, the Piranha Model P-140 is truly the king of single operator ironworker machines. The P-140 has more standard workstations than any other ironworker in its class. This includes punching, bending, bar shear, angle shear, round bar shear, and an integrated coper/notcher. It also has a dovetail slide that allows an operator to switch from punching to bending in just a few seconds. The P-140 has full electrical control of its stroke with a footswitch and limit switch stroke controls for fast punching cycles.

  • Complete Punching Attachment with split dove tail mounting
  • 5 Punch and Die sets
  • Automatic Urethane Hold Down on the Punch Stripper and on Angle, Plate and Bar Shear
  • Front and rear 5 position joy stick controls (electric) with jog up & down, fast up & down, neutral
  • Remote Electric Foot Switch that can be connected at either end of the machine
  • Electric Limit Switches that can be set for stroke control when using foot control
  • Set of Round Bar Knives [2 way] (customers choice to 2)
  • Set of 16.625 Plate Shear Knives [4 way]
  • Set of 20.5″ Plate Shear Knives [4 way] (instead of Round Bar Knives and 16.625″ Plate Shear Knives)
  • Extra Blank Knife to extend shear to 20.5″
  • Set of Angle Knives [8 way top] [4 way bottom]
  • Set of Coper Knives [2 way top] [4 way bottom]
  • Chip Buckets (2 each)
  • Extra Oil Filter
  • Coupling Wrench & 3/8″ Allen Wrench
  • Integral Lifting Lug for instant portability
pii-88

PII-88 Dual Operator Ironworker Machine

The Piranha Model PII-88 ironworker has dual-operator controls for the punch station and shear/coper stations and an Automatic Urethane Hold Down on the Plate and Angle Shear. Both ends of the machine can be operated independently of each other at the same time. A large, open punch station allows the use of a virtually unlimited range of standard accessories and special tooling, in addition to a 24″ plate shear capacity.

  • Complete Punching Attachment with stripper
  • 5 Punch and Die sets
  • Front and rear 2 position joy stick controls (electric)
  • Front and rear Remote Electric Foot Switches
  • Front limit switch stroke control
  • Set of Round Bar Knives [2 way] (customers choice to 1-1/2″)
  • Set of 20.625″ Plate Shear Knives [4 way]
  • Set of Blank Knives to extend shear to 24″
  • Set of Coper Knives [2 way top] [4 way bottom]
  • Set of Angle Shear Knives [8 way top] [4 way bottom]
  • Chip Buckets (coper end)
  • Extra Oil Filter
  • Coupling Wrench
  • Intergral Lifting Lug for instant portability
pii-140

PII-140 Dual Operator Ironworker Machine

The Piranha Model PII-140 ironworker has dual-operator electric controls (foot pedal and joystick) for the punch stations and shear/coper stations. Also featured are Automatic Urethane Hold Downs on the Angle, Plate, and Bar Shears. The large, open punch station allows the use of a virtually unlimited range of standard accessories and special tooling.

  • Complete Punching Attachment with stripper
  • 5 Punch and Die sets
  • Automatic Urethane Hold Down on the Plate, Angle, and Bar Shear
  • Front and rear 2 position joy stick controls (electric)
  • Front and rear Remote Electric Foot Switches
  • Front limit switch stroke control
  • Set of Round Bar Knives [2 way] (customers choice to 2″)
  • Set of 14.5″ Plate Shear Knives [4 way]: For PII-110
  • Set of 16.625″ Plate Shear Knives [4 way]: For PII-140
  • Set of 20.5″ Plate Shear Knives [4 way] instead of Round Bar Knives and 16.625″ Plate Shear
  • Knives: For PII-140
  • Extra Blank Knife to extend shear to 18″ on PII-110 or 20.5″ on PII-140
  • Set of Coper Knives [2 way top] [4 way bottom]
  • Set of Angle Shear Knives [2 way top] [4 way bottom]
  • Chip Buckets (coper end)
  • Extra Oil Filter
  • Coupling Wrench
  • Intergral Lifting Lug for instant portability
sep120

Piranha Single End Punch SEP-120

The SEP-120 is the most cost-effective 120-ton single end punch manufactured in America. The machine features a 21.5″ throat that allows the use of a wide range of tooling and accessories.

  • Complete Punching Attachment with stripper
  • Electric Limit Switches for stroke control
  • 5 Punch and Die set
  • 5 Position joy stick control (electric) with jog up & down,fast up & down, neutral
  • Remote Electric Foot Switch
  • Coupling Wrench
  • Integral Lifting Lug for instant portability
  • Extra Oil Filter
  • Remote Reservoir and Power Unit
