Watts-W-124Machine

W-124

W-124 Computer controlled pipe cutting machine conveys and rotates pipe from 2″ to 12.75″ OD with a 24′-50′ machine bed capable of supporting 300 lbs. per foot to a maximum of 6,000 lbs. to include:

  • 6-axis profiling carriage on precision machined and hardened track. Simultaneous motion maintains the torch cutting position along the linear axis of the pipe and perpendicular to the linear axis to perform beveled holes and end cuts.
  • Tracking torch head includes vertical and horizontal tracking mechanisms to maintain torch height and pipe centerline to automatically compensation for bent or out-of-round pipe.
  • Floating pipe clamp with a locking mechanism for an accurate rotation that eliminates pipe walk.
  • 3D pipe cutting software for at-machine and remote pipe cut programming and job management. The software vastly simplifies the importing, design, and nesting of parts, streamlines job estimating, scheduling and inventory management, and allows job tracking in real-time.
